The FOX 32 Float Rhythm fork with 110 mm of travel and the SCOTT RideLoc remote system allow riders to adapt the suspension to different terrain conditions. The SRAM Eagle 70 Transmission 12-speed drivetrain provides precise shifting and a wide gear range, while Shimano hydraulic disc brakes deliver reliable stopping power. Syncros tubeless-ready wheels and 29-inch Maxxis Rekon Race tyres complete a setup designed for speed and efficiency on XC courses.
-
Frame: Scale Carbon HMF, adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92, UDH interface, Boost 12x148 mm, 55 mm chainline
-
Fork: FOX 32 Float Rhythm Grip, 3 modes, 15x110 mm axle, 44 mm offset, tapered steerer, rebound adjustment and lockout, 110 mm travel
-
Remote Lockout: SCOTT RideLoc Technology, 3 suspension adjustment modes
-
Rear Derailleur: SRAM Eagle 70 Transmission, 12-speed
-
Shifters: SRAM Eagle 70 Trigger
-
Crankset: SRAM Eagle 70 Transmission DUB, 55 mm chainline, 32T chainring
-
Chain Guide: SCOTT Custom
-
Bottom Bracket: SRAM DUB PF92 MTB Wide, 41x92 mm shell
-
Chain: SRAM CN Eagle 70 Transmission
-
Cassette: SRAM Eagle XS 1270 V2 Transmission, 10–52T
-
Brakes: Shimano MT401 hydraulic disc brakes
-
Brake Rotors: Shimano SM-RT10 Center Lock, 180 mm front and 160 mm rear
-
Handlebar: Syncros Alloy 6061, flat, 740 mm width, 9° backsweep
-
Grips: Syncros Performance XC Lock-On
-
Stem: Syncros DC 3.0, Cable Integration System, 6061 alloy, 31.8 mm diameter
-
Dropper Seatpost: Syncros Duncan, 31.6 mm diameter; 100 mm travel (S), 130 mm (M), 150 mm (L/XL)
-
Saddle: Syncros Belcarra Regular 2.5
-
Headset: Syncros-Acros Angle Adjust & Cable Routing, ±0.6° head angle adjustment
-
Front Hub: Formula CL-811, 15x110 mm
-
Rear Hub: Formula CL-3248, 12x148 mm
-
Spokes: Black stainless steel, 15G, 1.8 mm
-
Rims: Syncros X-30SE, 32 holes, 30 mm internal width, Tubeless Ready
-
Tyres: Maxxis Rekon Race, 29x2.4", 120 TPI, folding bead, EXO, Tubeless Ready
